THS200 Hollow Rotary Actuator

Among motion control solutions, the Hollow Rotary Actuator stands apart due to its dual functionality – it functions as both a
high-performance rotary drive capable of executing precise turns and a conduit for essential services, making it ideal for
tight-space installations and demanding precision-driven applications.

Specifications	THS200-18
Reduction ratio	18
Positioning accuracy	0.5arcmin
Allowable torque	5Nm
Permissible speed	200r/min
Repetitive positioning accuracy	5arcsec
Allowable inertia load	2116N
Allowable axial load	4000Nm
Deviation of rotating platform tabletop	0.005mm
Parallelism of rotating platform	0.015mm
Concentricity of rotating platform	0.01mm
Rotating platform bearings	Cross Roller Bearing
Protection and other records	IP40
Moment of inertia	2500*0.000001kg.m²
Weight	8.2kg
Appearance dimensions	86mm
Phase number	2PHASES
Rated current	5A/PHASES
Coil impedance	0.43±10%OHM/PHASE
Coil impedance	3.5MH
Maintain torque	4.5kg.cm
Moment of inertia	1600g.cm
Motor length	Open loop: 81mm Closed loop: 101mm
Encoder resolution	/
Insulation level	B
Step angle	1.8°
Lead	1000

Basic Structure of the Hollow Rotary Actuator

1.Cross roller bearings: provide high stiffness and precise rotational support.

2.Precision gears: torque amplification and speed control are achieved through transmission devices such as planetary gears.

3. Input installation flange: Connect the motor or other drive source to ensure stable power transmission.

4.Input shaft: transmits the rotation of the motor to the internal gear system and may be designed hollow for passing through cables or pipelines.

5.Induction device: such as an encoder, used for real-time detection and feedback of actuator position information, achieving precise control.

We are a modern enterprise that specializes in the development, production, sales, and service of professional servo electric cylinders, servo press equipment, and other servo stamping equipment. Our company has a professional design team, processing team, assembly team, sales team, and after-sales service team. We mainly research and develop servo cylinders, servo presses, electric push rods, electric slide tables, and multi-degree-of-freedom platforms. Our company always adheres to the business philosophy of "integrity, sincerity, stability, and compliance", and always strives for excellence in design, manufacturing, and service.
