High-Speed Precision Set Grinded CM.CDM Series Ball Screw Vietnam Manufactory Core Bearing Gear Motor Pump Engine Tariff-Free

Send Inquiry

Product Description

Ball screw pair is a mechanical element composed of screw, nut, ball and other parts. Its function is to convert rotary motion into linear motion or linear motion into rotary motion. It is a further development of traditional sliding screw. The profound significance of this development is the same as the change brought by rolling bearings to sliding bearings. Ball screw pairs are widely used in various industrial equipment, precision instruments and precision CNC machine tools due to their excellent friction characteristics.

Since our company developed the first set of ball screw pairs in Vietnam in 1964, the company has always led and penetrated the development of domestic ball screw pairs in terms of technical development of ball screw pairs, and has always been in a leading position in the domestic research and development and manufacturing of ball screw pairs. In order to adapt to the development of CNC machine tools, the company has established the product development direction of "large-scale, heavy-duty, high-speed and high-precision". In the product research and development, it has successively launched a number of new products with independent intellectual property rights, such as dkfzd end block high-speed and high-precision ball screw pairs, JF / jfzd matrix large-scale heavy-duty ball screw pairs, and has applied for and authorized more than 30 patents. In terms of processing technology, the company was the first to apply induction hardening technology to the heat treatment of ball screw pairs, which greatly improved the production efficiency of ball screw pairs. In recent years, the company has successfully introduced the world-class processing technology of leistritz high-speed hardware rotary milling machine and hardware material rotary milling, which has changed the traditional processing technology for decades, improved the production capacity and quality, and greatly shortened the product production cycle. Using pre batch sizing processing, the supply cycle of products can be shortened to 15 days.

At present, the company can produce the smallest diameter Φ 6mm, lead 1mm; The maximum specification diameter is Φ 245mm; The length of a single screw is 10m, and the maximum dynamic load rating is 125t. It is suitable for ball screw pairs in various applications; It can provide all kinds of ball screw pairs of 2m P1, 3M P2, 5m P3 and 10m P5 in batches. It is a professional manufacturer of ball screw pairs with the largest variety and the most complete specifications in Vietnam.

Characteristics of ball screw pair

(1) high transmission efficiency

(2) high positioning accuracy

(3) transmission reversibility

(4) long service life

(5) good synchronization performance

Product Name	BTP Ball Screw Precision Level Acceptable Customization 0-4000 Long SFU 1604
Material	Bearing Steel
Color	nickel white
Standard	DIN GB ISO JIS BA ANSI
Application	automatic machinery
Grade	4,5 or according to customers' requirements
Thread	Milled Thread
Warranty	12 months

For more details, please click here to contact us!

Q: Are you trading company or manufacturer ? A: Our group consists in 3 factories and 2 abroad sales corporations. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: How long is your delivery time ? What is your terms of payment ? A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment. Q: What is the exact MOQ or price for your product ? A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation. If you have another question, please feel free to contact us.
