Tariff-free Zlyj 146 173 180 200 225 375 420 Reduction Single Twin Screw Plastic Extruder Helical Gearbox Reducer

ZLYJ series gearbox is one kind of gear transmission with thrust package for plastic, rubber extruder . Product Design reference JB / T8853-2001 the technical specifications "cylindrical gear reducer" Regulations. It features gears and shaft parts with a high-strength alloy steel. Gear by ......

Send Inquiry

Product Description

ZLYJ series gearbox is one kind of gear transmission with thrust package for plastic, rubber extruder . Product Design reference JB / T8853-2001 the technical specifications "cylindrical gear reducer" Regulations. It features gears and shaft parts with a high-strength alloy steel. Gear by carburizing, quenching, grinding teeth processing technology. Gear accuracy GB10095-88,level 6. Axial thrust gear hardness of HRC54-62. In the front end of the hollow output shaft is equipped with large-sized thrust bearings to withstand the screw at work. Machine is small, high carrying capacity, smooth transmission, low noise and high efficiency etc.

Type	Ratio Range	Power(KW)	Input speed (r/min)	Output speed (r/min)	Axial Thrust(KN)	Screw Diameter (mm)
ZLYJ112	8/10/12.5	5.5	800	100	35	φ35
ZLYJ133	8/10/12.5/14/16/18/20	8	800	100	39	φ50
ZLYJ146			11	900	90	54	φ55
ZLYJ173			18.5	900	90	110	φ65
ZLYJ200			26	1000	80	155	φ75
ZLYJ225			45	1000	80	180	φ90
ZLYJ250			45	1120	70	192	φ100
ZLYJ280			45	960	60	258	φ105,110
ZLYJ315			75	960	60	287	φ120
ZLYJ330			132	960	60	390	φ130,150
ZLYJ375			132	960	60	390	φ150,160
ZLYJ420			160	960	60	430	φ165
ZLYJ450			213	1200	60	500	φ165

1.The gears are carburized, quenched and ground. Gear accuracy gb10095-88,

2.Six-level hard gear, hardness HRC54~62.

3.The front part of the hollow output shaft is equipped with a large thrust bearing, which can bear the axial thrust when the screw is working.

4. small size, large bearing capacity and stable operation.

5.Transmission, low noise and high efficiency.
