Tariff-free ZLYJ112 Speed Reduction Single Twin Screw Plastic Extruder Reducer Helical Gearbox

ZLYJ112 Plastic Extruder GearboxScrew diameter: 35Adapted power:5.5kWSpeed ratio:8, 12.5, 16, 20 Aperture: 35Key pin:10 Flange diameter:185TypeRatio RangePower(KW)Input speed (r/min)Output speed (r/min)Axial Thrust(KN)Screw Diameter(mm)ZLYJ1128/10/12.55.580010035φ35ZLYJ1338/10/12.5/14/16/18/2088001......

Send Inquiry

Product Description

ZLYJ112 Plastic Extruder Gearbox

Screw diameter: 35

Adapted power:5.5kW

Speed ratio:8, 12.5, 16, 20

Aperture: 35

Key pin:10

Flange diameter:185

Type	Ratio Range	Power(KW)	Input speed (r/min)	Output speed (r/min)	Axial Thrust(KN)	Screw Diameter (mm)
ZLYJ112	8/10/12.5	5.5	800	100	35	φ35
ZLYJ133	8/10/12.5/14/16/18/20	8	800	100	39	φ50
ZLYJ146			11	900	90	54	φ55
ZLYJ173			18.5	900	90	110	φ65
ZLYJ200			26	1000	80	155	φ75
ZLYJ225			45	1000	80	180	φ90
ZLYJ250			45	1120	70	192	φ100
ZLYJ280			45	960	60	258	φ105,110
ZLYJ315			75	960	60	287	φ120
ZLYJ330			132	960	60	390	φ130,150
ZLYJ375			132	960	60	390	φ150,160
ZLYJ420			160	960	60	430	φ165
ZLYJ450			213	1200	60	500	φ165

1.The gears are carburized, quenched and ground. Gear accuracy gb10095-88,

2.Six-level hard gear, hardness HRC54~62.

3.The front part of the hollow output shaft is equipped with a large thrust bearing, which can bear the axial thrust when the screw is working.

4. small size, large bearing capacity and stable operation.

5.Transmission, low noise and high efficiency.

Raydafon GROUP CO., LTD. IS SPECIALIST IN MAKING ALL KINDS OF MECHANICAL TRANSMISSION AND HYDRAULIC TRANSMISSION LIKE: PLANETARY GEARBOXES, WORM REDUCERS, IN-LINE HELICAL GEAR SPEED REDUCERS, PARALLEL SHAFT HELICAL GEAR REDUCERS, HELICAL BEVEL REDUCERS, HELICAL WORM GEAR REDUCERS, AGRICULTURAL GEARBOXES, TRACTOR GEARBOXES, AUTO GEARBOXES, PTO DRIVE SHAFTS, SPECIAL REDUCER & RELATED GEAR COMPONENTS AND OTHER RELATED PRODUCTS, SPROCKETS, HYDRAULIC SYSTEM, VACCUM PUMPS, FLUID COUPLING, GEAR RACKS, CHAINS, TIMING PULLEYS, UDL SPEED VARIATORS, V PULLEYS, HYDRAULIC CYLINDER, GEAR PUMPS, SCREW AIR COMPRESSORS, SHAFT COLLARS LOW BACKLASH WORM REDUCERS AND SO ON. FURTHERMORE, WE CAN PRODUCE CUSTOMIZED VARIATORS, GEARED MOTORS, ELECTRIC MOTORS AND OTHER HYDRAULIC PRODUCTS ACCORDING TO CUSTOMERS’ DRAWINGS.
